YSD HGS Series

HYDRAULIC/NC/CNC GUILLOTINE SHEARING

new

Standard
Accessories

Electricals
Control Panel
Motorised Back Gauge
Squaring Arm
Ball Transfer
4 Edged Hc Blade

Optional
Accessories

Nc Back Gauge With Ysd 300s Controller.
Cnc Back Gauge With Delem Dac 310 Controller With Servo Drive & Servo Motor.
Cnc Controlled Back Gauge, Shearing Angle, Blade Clearance & Shearing Length With Delem Dac 360 Controller, Servo Drive & Servo Motor.
Deep Throat.
Thin Sheet Support System.
Longer Squaring Arm

SPECIFICATIONS

MODEL		HGS (K) 62/6	HGS (K) 40/13	HGS (K) 62/13	HGS (K) 80/13	HGS (K) 120/13	HGS (K) 40/20	HGS (K) 62/20	HGS (K) 65/20	HGS (K) 80/20	HGS (K) 25/25	HGS (K) 31/25	HGS (K) 40/25
MAX. CUTTING THICKNESS (MILD STEEL 45 KG/MM2)	mm	6	13	13	13	13	20	20	20	20	25	25	25
MAX CUTTING LENGTH	mm	6200	4000	6200	8000	12000	4000	6200	6500	8000	2500	3100	4000
CUTTING FORCE	KN	132	730	620	620	650	1270	1400	1400	1400	1960	2320	1600
BACK GAUGE RANGE	mm	1000	1000	1000	1000	1000	1000	1000	1000	1000	1000	1000	1000
RAKE ANGLE ADJUSTMENT	0	0.5 - 2.5	0.5 - 2	0.5 - 2.5	0.5 - 2.5	0.3 - 2	0.5 - 3	0.5 - 2.5	0.5-2.5	0.5-2.5	0.5-3	0.5-2.5	0.5-3.5
STROKES PER MINUTE		7	10	7	7	5	5	5	5	4	6	6	5
DEPTH OF THROAT	mm	100	200	60	400	100	300	100	200	100	300	300	300
NUMBER OF HOLDOWNS		32	20	32	42	61	20	32	35	40	13	26	20
VOLUME OF OIL TANK	L	686	561	686	1600	1600	627	1500	1500	1800	828	1068	1100
MOTOR POWER	KW	15	22	30	2 x 30	2 x 30	30	2 x 30	2 x 30	2 x 37	45	45	2 x 30
WEIGHT	Kg	20000	17000	28000	55000	150000	29000	55000	65000	98000	25000	29000	38000
DIMENSIONS LENGTH	mm	7065	4885	7100	9090	13760	5050	7320	7620	9250	3585	4260	5360
DIMENSIONS WIDTH	mm	2250	2190	2330	2900	3350	2500	2860	2910		2800	2900	2900
DIMENSIONS	mm	2630	2715	2680	3525	4025	3530	3500	3550	3725	3325	3425	3390
DIMENSIONS HEIGHT	mm	2650	2490	2830	3360	5200	3140	3390	3430	3760	2835	2885	3420

MODEL		HGS (K) 25/30	HGS (K) 31/30	HGS (K) 25/40	HGS (K) 25/16	HGS (K) 31/16	HGS (K) 40/16	HGS (K) 50/16	HGS (K) 62/16	HGS (K) 80/16	HGS (K) 21/20	HGS (K) 25/20	HGS (K) 31/20
MAX. CUTTING THICKNESS (MILD STEEL 45 KG/MM2)	mm	30	30	40	16	16	16	16	16	16	20	20	20
MAX CUTTING LENGTH	mm	2500	3100	2500	2500	3100	4000	5000	6200	8000	2100	2500	3100
CUTTING FORCE	KN	2200	2200	3700	730	850	850	850	850	850	1270	1270	1370
BACK GAUGE RANGE	mm	1000	1000	1000	1000	1000	1000	1000	1000	1000	1000	1000	1000
RAKE ANGLE ADJUSTMENT	0	0.5-3.5	0.5-3.5	0.5-3.5	0.5-3	0.5-2.5	0.5-2.5	0.5-2.5	0.5-2.5	0.5-2.5	0.5-3	0.5-3	0.5-2.5
STROKES PER MINUTE		4	4	3	9	8	8	6	7	7	7	7	7
DEPTH OF THROAT	mm	300	300	200	300	300	200	100	100	650	300	300	300
NUMBER OF HOLDOWNS		13	16	13	13	16	20	26	32	42	11	13	16
VOLUME OF OIL TANK	L	920	1300	1200	500	590	560	662	686	1800	370	500	590
MOTOR POWER	KW	55	55	2 x 37	22	22	30	37	37	2 x 30	30	30	30
WEIGHT	Kg	29000	32000	39500	11000	12000	18000	28000	36000	85000	13000	14000	15000
DIMENSIONS LENGTH	mm	3885	4485	4105	3265	3865	5020	5935	7185	9150	2970	3370	3970
DIMENSIONS WIDTH	mm	2950	2950	3050	2140	2140	2240	2360	2350	3250	2275	2275	2275
DIMENSIONS	mm	3435	3435	3960	2675	2675	2715	2680	2750	3875	2800	2800	2800
DIMENSIONS HEIGHT	mm	3085	3085	3375	2350	2350	2575	2870	2860	3520	2470	2470	2470

Please Note: The manufacturer reserve rights to modify design, specifications, mechanism, etc. to improve the performance of this machine without notice.
